Learning Process Note:

The Handheld Remote Control System has a learning frequency function to prevent potential interference from other remote units. Follow these steps to set it up:

Step 1: The factory installs a 3V CR2032 lithium battery before delivery. Remove the battery isolation film. Within 30 seconds of turning on the receiver's AC power, press the transmitter's "LEARN" button.

Step 2: Hold the "LEARN" button for over 5 seconds. Once the receiver detects the frequency, it will emit two "Bi Bi" sounds, indicating successful learning of the previously selected frequency from the transmitter.

Note: After turning on the AC power, do not press any other button on the transmitter before pressing the "LEARN" button, as doing so will cause the procedure to fail.

After completing the steps above, you should be able to operate the ceiling fan and light. If the fan does not respond to the transmitter, please turn off the power to the receiver and repeat steps 1 and 2.

Light Function Switch:

For fans with dimmable bulbs, slide the "Light Function" switch (O/D) to the position marked "D". If you are using non-dimmable bulbs, slide the "Light Function" switch to the "O" position.

Battery Required : CR2032 Battery
Frequency Type : RF/Bluetooth
FCC ID : 2AQZU-18001
Frequency (MHz) : 304.250
Dimensions: 2.00 x 6.00 x 1.00 (W x L x D, inches)
