Learning Process:

The Handheld Remote Control System features a learning frequency function with code combinations to prevent potential interference from other remote units. Follow these steps to set it up:

Step 1: Install the 3V CR2032 lithium battery within 30 seconds of turning on the receiver's AC power. Press the transmitter's "LEARN" button.

Step 2: Hold the "LEARN" button for over 5 seconds. Once the receiver detects the frequency, it will emit two "Bi Bi" sounds, indicating successful learning of the previously selected frequency from the transmitter.

Note: After turning on the AC power, do not press any other button on the transmitter before pressing the "LEARN" button, as this may cause the procedure to fail.

After completing the steps above, you should be able to operate the ceiling fan and light. If the fan does not respond to the transmitter, turn off the power to the receiver and repeat steps 1 and 2.

Note: Remove the battery if the remote will not be used for long periods to prevent damage.

Battery Required : CR2032 Battery
Frequency Type : RF/Bluetooth
FCC ID : 2AQZU-TR252B
Frequency (MHz) : 304.250
Dimensions: 2.00 x 6.00 x 1.00 (W x L x D, inches)
